Reliable AC Power Control
The LC1-K series AC contactor is a compact and efficient switching device engineered for controlling AC motor circuits and managing frequent starting operations. Designed for safety and convenience, it offers robust overload protection when combined with a thermal relay, making it an ideal choice for diverse industrial and commercial environments. Its versatile design supports reliable operation across a wide range of power distribution and control applications.
Technical Specifications
- Rated Insulation Voltage (Ui)
- 690 V
- Impulse Withstand Voltage (Uimp)
- 8 kV
- Coil Voltage
- 220V (50/60Hz)
- Continuous Current
- 20 A
- Standards & Certifications
- CEIECNFCVDEBS
Performance Data
AC-3 Control Power & Current Ratings
| Model | Current (380V) | 220V (kW) | 380/415V (kW) | 440/500V (kW) | 600V (kW) |
|---|---|---|---|---|---|
| LP1-K06 | 6 | 1.5 | 2.2 | 3 | 3 |
| LP1-K09 | 9 | 2.2 | 4 | 4 | 4 |
| LP1-K12 | 12 | 3 | 5 | 5 | 5 |
Contact Configuration
3P+NC3P+NO
Applications
Common Use Cases
- Distribution boxes
- Computer centers
- Telecommunications rooms
- Elevator control rooms
- Industrial automatic control rooms
- Hospital operating rooms
