1.5P AC Contactor with 24V Coil
This AC contactor is designed for 1.5P air conditioning units. It features a 24V coil and robust construction for reliable performance in HVAC&R applications.
Technical Specifications
Overview
High-Performance 1.5P AC Contactor
Designed specifically for demanding HVAC&R applications, this 1.5P AC contactor ensures reliable operation in air conditioning systems. It features a robust EE magnet assembly for optimal performance and a dust-free internal construction that enhances longevity. With universal mounting capabilities and flexible termination options, this component is engineered for easy replacement and seamless integration into various electrical setups.
Performance Ratings
Life Cycle Ratings
250,000 cycles
Electrical Life
1,000,000 cycles
Mechanical Life
Contact Ratings Per Pole
| Voltage (VAC) | FLA | LRA | RES |
|---|---|---|---|
| 240/277 | 30 | 180 | 40 |
| 480 | 30 | 150 | 40 |
| 600 | 30 | 120 | 40 |
Technical Specifications
- Coil Voltage
- 208/240V AC
- Operating Frequency
- 50/60Hz
- Compliance
- ARI 780/790IEC60947-4-1UL CertifiedCE Certified
Installation
Torque Specifications (CU 75°C)
- Screws: 22 in-lbs
- Lugs: 40 in-lbs
- Mounting Type
- Universal metal mounting plate
