600mm PP Melt Blown Non Woven Fabric Machine
This machine produces non-woven fabrics using the melt-blown process with polypropylene as the raw material. It is capable of producing fabrics with various thicknesses and densities.
Technical Specifications
Overview
High-Performance Melt Blown Fabric Production
The AF-600mm is a professional-grade PP melt blown non-woven fabric machine backed by over 10 years of manufacturing expertise. It utilizes a single screw extruder and high-speed hot air stretching to produce microfibers as fine as 1 to 5 microns, resulting in fabrics with superior filtering, shielding, and insulation properties. This highly automated line is designed for the efficient production of materials used in medical masks, liquid filtration, and thermal insulation.
Key Performance Metrics
Performance Highlights
200 kg/day
Max Daily Capacity
600 mm
Mold Width
100 gsm
Max Fabric Weight
Technical Specifications
Technical Data
| Parameter | Value |
|---|---|
| Raw Material | 100% New Polypropylene |
| Fiber Micro | 15-30μm |
| Fabric Width | 525mm |
| Fabric Thickness | 2-5mm |
| Mole Hole Size | 0.2-0.4mm (Customizable) |
Power & Energy
Power Requirements
- Total Installed Power: 40-60kw
- Voltage: 380V
- Actual Running Consumption: 20-25KWH
Operational Features
Machine Features
- Highly automated production line
- PLC controlled with touch-screen interface
- Well-known high-performance control elements
- Customizable main frame and auxiliary equipment configuration
- Integrated edge material recycling
Applications
- Common Applications
- Air FiltrationLiquid FiltrationMedical TextilesIsolation MaterialsOil AbsorptionWiping ClothsThermal Insulation
Production Process
Working Process Flow
- Raw Material Feeding / Edge Recycling
- Melt Extrusion
- Meltblow Device Processing
- Web Forming Machine
- Winding and Slitting
- Finished Product Collection
