22mm Control Selector Switch
This 22mm selector switch is designed for push button control applications. It features a robust construction and is suitable for various industrial control panels and equipment.
Technical Specifications
Product Overview
Industrial Control Solutions
The 22mm selector switch series is designed for reliable performance in demanding industrial control circuits, including AC voltages up to 660V and DC voltages below 400V. Featuring high-grade anti-flame plastics and silver alloy contacts, these switches offer excellent resistance to electrical erosion. With versatile mounting options and compatibility with various signal and interlocking applications, this series meets international standards for quality and safety.
Technical Specifications
Electrical Ratings
660 V
Max AC Voltage
400 V
Max DC Voltage
10 A
Heating Current
Insulation Performance
| Parameter | Value |
|---|---|
| Rated Insulation Voltage | 600V AC |
| Insulation Resistance | ≥50MΩ |
| Contact Resistance | ≤25mΩ |
| Withstand Voltage | 2.5KV/min |
Standards & Compliance
International Standards
- GB/T14048.1
- IEC60947-5-1
- Certifications
- CEISO9001ROHSUL
Durability
Operational Lifespan
| Component | Mechanical Life | Electrical Life |
|---|---|---|
| Push Button | 1,000,000 cycles | 5,000,000 cycles |
| Selector Switch | 500,000 cycles | 250,000 cycles |
