2-Pole AC Definite Purpose Contactor 20A
Definite purpose contactors are suitable for heating, air conditioning, refrigeration, data processing, and food service equipment. These 2-pole contactors are designed for motor control applications requiring a cost-effective and reliable component.
Technical Specifications
Product Overview
Definite Purpose AC Contactor
This 2-pole definite purpose magnetic contactor is engineered for reliable performance in HVAC and refrigeration applications. Designed to handle demanding electrical loads, it features robust construction and complies with international safety standards. It provides dependable switching for hermetic refrigeration compressors and other AC systems.
Electrical Ratings
Contact Ratings Table
| Voltage (VAC) | FLA | LRA | Resistive (A) |
|---|---|---|---|
| 240/277 | 30 | 180 | 40 |
| 480 | 30 | 150 | 40 |
| 600 | 30 | 120 | 40 |
- Rated Current
- 20 A
- Coil Voltage
- 24VAC
- Frequency
- 50/60 Hz
Technical Standards
Performance Metrics
20 A @ 277V
AC-1 Rating
15 A @ 277V
AC-3 Rating
- Compliance
- CUL CertifiedIEC60947-4-1
Installation
Torque Specifications (CU 75°C)
- Screws: 22 in lbs
- Lugs: 40 in lbs
Ordering Information
Shipping & Payment
- Delivery Time: 15-20 days after deposit
- Payment Terms: 30% deposit, balance against B/L copy
- Samples available upon request
