2-Pole 20 FLA HVAC Contactor 24V 220V
This is a 2-pole DP contactor with 20 FLA, designed for electrical equipment and accessories. It is suitable for various brands of air conditioning equipment.
Technical Specifications
Product Overview
Professional HVAC Contactor
This 2-pole definite purpose contactor is designed for reliable switching in air conditioning and refrigeration systems. Engineered to handle high-demand electrical loads, it provides a direct, safe replacement for discontinued components. Built for versatility, it is compatible with a wide range of residential and commercial cooling units.
Electrical Specifications
- Electricity Type
- AC
- Coil Voltage
- 208V/240V
- Number of Poles
- 2
- Main Circuit Voltage
- 600 V
- Rated Current
- 30A-40A
Performance & Lifecycle
Electrical Life
200,000 operations
Cycles
Mechanical Life
600,000 operations
Cycles
Certifications & Compliance
- Certifications
- ULCSACES markCCC
Installation Data
Torque Specifications
| Component | Torque |
|---|---|
| Screws | 20 in-lbs |
| Lugs | 40 in-lbs |
