150 Amp 3P Miniature Circuit Breaker
This miniature circuit breaker is rated for 150 amps and designed with three poles. It provides reliable protection against overloads and short circuits in electrical systems.
Technical Specifications
Overview
Professional Miniature Circuit Breaker
This 3-pole miniature circuit breaker is engineered for reliable overload and short-circuit protection in residential, commercial, and industrial electrical systems. Featuring a thermal-magnetic trip mechanism and a 30mA leakage current protection, it ensures safety and operational efficiency. Designed for standard DIN rail mounting, this unit includes convenient test and reset functions for easy maintenance.
Electrical Ratings
- Rated Voltage
- 400 V
- Rated Current
- 150 A
- Breaking Capacity
- 6000 A
- Leakage Current Protection
- 30 mA
Technical Features
- Number of Poles
- 3
- Mounting Type
- DIN Rail
- Trip Mechanism
- Thermal-magnetic
Maintenance & Safety
Standards Compliance
IEC Compliant
- Safety Features
- Reset ButtonTest ButtonVisible Trip IndicatorON/OFF Indicator
