1.14kV AC Vacuum Contactor
This AC vacuum contactor is designed for power systems with AC 50Hz and rated working voltage of 660~1140V. It is used for remote making and breaking circuit, and frequent starting and control of AC motors, transformers and capacitor banks.
Technical Specifications
Product Overview
High-Performance Vacuum Contactor
The VACJP series is a robust low-voltage AC vacuum contactor engineered for demanding power systems. Designed for reliability in harsh environments, it excels at remote circuit making and breaking, as well as the frequent starting and control of AC motors, transformers, and capacitor banks. Its versatility makes it an ideal component for building anti-explosion magnetic starters in critical industries like mining, metallurgy, and chemical processing.
Electrical Ratings
- Rated Working Voltage
- 1140 V
- Rated Current Range
- 125 - 630 A
- Frequency
- 50 Hz
Operating Environment
- Operating Temperature
- -5°C to +40°C
- Maximum Altitude
- 1000 m
- Max Humidity (Wet Month)
- 90 %
Installation & Compliance
- Installation Type
- III
- Pollution Degree
- 3
- Max Installation Slant Angle
- 15 degrees
Applications
- Suitable Industries
- MiningMetallurgyPetroleumChemicalPowerTransportationShippingBuilding Materials
