110kV Urban Power Substation
This 110kV city center substation is a compact and efficient solution for urban power distribution. The substation integrates high-voltage transformers, switchgear, and control systems within a secure, weather-resistant enclosure.
Technical Specifications
Overview
Advanced Urban Power Distribution
This 110kV Urban Power Substation is a compact and efficient solution designed for high-density city centers and industrial zones. It integrates high-voltage transformers, switchgear, and advanced control systems within a secure, weather-resistant E-House enclosure. Engineered for minimal environmental impact, it features acoustic shielding and a reduced footprint to ensure reliable power delivery in congested areas.
Performance Metrics
Key Performance Indicators
110 kV
Voltage Rating
40 dB
Noise Level
420 m2
Minimum Land Area
Installation & Efficiency
- Construction Timeline
- 3 to 6 months
- Commissioning Timeline
- 1 month or less
Environmental & Safety
Safety Design
- Safe-to-touch E-House enclosures
- Integrated fire-fighting equipment
- Robust safety signage and fencing
- Surge arresters for overvoltage protection
- Shielding & Protection
- Acoustic ShieldingElectromagnetic ShieldingRadiation ReductionVandalism Protection
Technical Configuration
System Components
- High-voltage step-down transformers
- Circuit protection switchgear
- Remote control buildings
- Overhead busbars and insulators
- Disconnectors
Voltage Levels Supported
110kV35kV10kV
Smart Capabilities
Smart Grid Integration
- Advanced monitoring systems
- Remote control capabilities
- Smart box-type substation integration
- Efficient energy management
Customization
- Aesthetic Customization
- Custom paint work available to blend with urban surroundings
