Wood-Based Panel Universal Testing Machine
This universal testing machine is designed for testing wood-based panels using tensile, compression, and bending methods. The machine features a manual rotation wheel that drives the chuck for accurate and reliable testing.
Technical Specifications
Product Overview
Professional Wood-Based Panel Testing
The MWD-10B is a specialized universal testing machine engineered for the precise evaluation of wood-based panels and plywood. It utilizes a reliable manual rotation wheel system to perform critical quality assurance tasks, including tensile, compression, and flexural strength tests. This versatile unit is an essential tool for manufacturers and quality inspection departments seeking accurate data on elastic modulus, bond strength, and structural integrity.
Technical Specifications
Maximum Test Force
10,000 N
Maximum Force
- Testing Range
- 0.4-10 kN
- Effective Test Width
- 400 mm
Operational Details
Display and Control
- Large LCD real-time display
- Peak hold function
- Manual operation
- Loading Method
- Manual rotation wheel
Physical and Power
- Host Dimensions
- 520 x 450 x 1000 mm
- Net Weight
- 100 kg
- Power Voltage
- 220V ± 10%
Supported Tests
- Available Testing Applications
- Tensile strengthCompressive strengthFlexural strengthBending strengthElastic modulusInternal bond strengthSurface bonding strengthPlywood shear tests
