T45 Degree Copper Tube Terminals

These T45 degree copper tube terminals connect copper conductors in power cables to electronic equipment. They are made of 99.99% pure copper tube and coated with tin, suitable for working temperatures from -55oC to 150oC.

Request a Quote Download PDFPDF

Technical Specifications

Product Overview

High-Conductivity T45° Tube Terminals

These T45° angled copper tube terminals are engineered for reliable electrical connections in power distribution and industrial equipment. Manufactured from 99.99% pure T2 copper and tin-plated for enhanced corrosion resistance, they ensure optimal electrical transmission with minimal voltage drop. The specific 45-degree palm angle facilitates secure connections in confined or angled installation spaces.

Technical Specifications

Conductor Range: 10-240mm²
Copper Purity: 99.99 %
Surface Treatment: Tin Plated

Environmental Ratings

Operating Temperature

-55 °C

Min Temperature

150 °C

Max Temperature

Compliance & Quality

Industry Certifications: ISO 9001:2015IATF 16949IRISRoHS

Vous souhaitez sourcer ce produit ?

Soumettez une demande pour être mis en relation avec des fabricants vérifiés qui produisent ce produit.
