Solid State Relay 24-480VAC
This solid state relay is designed for electric air conditioners, fans, and refrigerators. It provides reliable switching for HVAC&R applications.
Technical Specifications
Product Overview
High-Performance Solid State Relay
This SSR-90DA series solid state relay is designed for reliable switching in demanding HVAC&R applications, including electric air conditioners, fans, and refrigerators. Featuring a semiconductor-based design, it offers faster switching speeds, a longer operational lifespan, and silent operation compared to traditional electromechanical relays. The unit is built for durability with high dielectric strength and integrated LED work instructions for easy status monitoring.
Key Performance Metrics
Performance Highlights
480 VAC
Max Load Voltage
2,500 VAC
Dielectric Strength
10 ms
Max On-Off Time
Electrical Specifications
- Load Voltage Range
- 24~480VAC
- Control Voltage
- 3-32VDC
- Control Current
- DC 4-25mA
- On-state Voltage Drop
- ≤1.5V
- Off-state Leakage Current
- ≤2mA
- Insulation Resistance
- 1000MΩ / 500VDC
Physical & Environmental
- Dimensions (LxWxH)
- 62mm x 45mm x 23.5mm
- Unit Weight
- 132 g
- Operating Temperature
- -30℃ to +75℃
- Mounting Method
- Bolting
Features & Certifications
Compliance & Certifications
CECULUL
- Available Current Ratings
- 10A15A20A25A30A40A60A75A80A90A100A
- Status Indicator
- Integrated LED
