Single Spindle Boring Machine
The single spindle boring machine is designed for precise drilling and boring operations. It features a robust frame, adjustable worktable, and a user-friendly control panel for easy operation.
Technical Specifications
Overview
Professional Woodworking Drilling Solution
The single spindle boring machine is a high-efficiency tool designed for accurate horizontal and vertical drilling in solid wood, shavings, and MDF. It features a pneumatically tiltable boring unit with versatile 0°, 45°, and 90° settings to accommodate complex mortise processes. Built for precision and ease of operation, this machine is an essential asset for high-volume woodworking production lines.
Technical Specifications
Spindle Configuration
21 pcs
Number of Bits
32 mm
Distance Between Spindles
2,840 rpm
Spindle Speed
Performance Parameters
1.5 KW
Motor Power
50 mm
Max Drilling Depth
0.6 Mpa
Air Pressure
Physical Attributes
Dimensions & Weight
| Attribute | Measurement |
|---|---|
| Outline Size | 1100 x 1400 x 1300 mm |
| Net Weight | 380 KG |
Features & Compatibility
Key Features
- Pneumatically tiltable boring unit (0°, 45°, 90°)
- Foldable guide bar for rip fence
- Supports both horizontal and vertical drilling
- Pneumatic foot pedal for clamping and drilling
- Quick-change chuck system
- Compliance
- CE Certified
