Precision Brass Fitting
This precision brass fitting is designed for secure connections. It is constructed from quality brass and ideal for plumbing and industrial applications.
Technical Specifications
Product Overview
Precision Brass Component
This precision-machined brass fitting is designed for high-performance fluid control and mechanical applications. Engineered with a durable, forged brass body and subjected to rigorous standard gauge checking, it ensures leak-proof reliability in demanding industrial environments. The design features a stepped, hexagonal configuration for secure wrenching and precise thread integration.
Technical Dimensions
Detailed Measurements
| Feature | Value | Unit |
|---|---|---|
| Overall Height | 107.6 | mm |
| Outlet Diameter 1 | 22 | mm |
| Outlet Diameter 2 | 17 | mm |
| Central Radius | 8 | mm |
| Central Diameter | 25 | mm |
| Base Thickness | 5 | mm |
| Total Thickness | 21.76 | mm |
Featured Metrics
120 degrees
Internal Angle
30 degrees
Outlet Angle
Manufacturing Standards
Custom Services
- Custom drawing support
- Sample development available
- Free mould and tooling making
- Free mailing of samples
- Quality Assurance
- Digital Lathe MachinedForged BodyStandard Gauge Checked
