Plate Top Turning Modular Plastic Conveyor Belt
This plate top turning modular conveyor belt is made of plastic and has a fixed inner radius. It is designed for efficient and reliable material handling.
Technical Specifications
Product Overview
High-Performance Modular Conveyor Belt
This plate top turning modular plastic conveyor belt features a fixed inner radius, designed for efficient material handling in complex layouts. Its modular construction allows for easy assembly and maintenance, while the robust plastic design ensures durability and chemical resistance. Ideal for food processing and industrial applications, this belt provides a stable, hygienic, and reliable conveying surface.
Technical Specifications
Dimensions and Geometry
| Specification | Value |
|---|---|
| Mini Inner Radius | 600mm |
| Thickness | 10mm |
| Minimum Width | 200mm |
| Open Area | 0% |
| Rod Diameter | 4.9mm |
| Curve Capability | Yes |
| Flight | No |
| Side Guard | No |
Performance & Materials
Performance Metrics
1.2 tons/m²
Max Load Capacity
260 °C
Max Temperature
-40 °C
Min Temperature
Available Colors
WhiteBlueGrayNatureDark-brown
- Material Composition
- PPPOMPEPA
Compliance & Hardware
Sprocket Configuration
- Sprocket Size: 12T
- Bore Type: Square Bore
- Certifications
- FDAEU
Applications
Industry Applications
- Food Industry (Meat, Poultry, Seafood, Bakery, Snack Food, Fruit & Vegetables)
- Automotive
- Tire Manufacturing
- Packaging
- Printing/Paper
- Postal
- Corrugated Cardboard
- Can Manufacturing
- PET Manufacturing
- Textile
