Petrol Concrete Vibrator with Flexible Shaft
This petrol concrete vibrator features double oil-seals and an anti-reverse device with pushbutton mode. It utilizes an alloy steel vibrator and a flexible hose made of MN steel sheet.
Technical Specifications
Overview
Professional Concrete Consolidation
This petrol-powered concrete vibrator is a professional-grade mechanized tool designed to eliminate air bubbles and voids in freshly poured concrete. By effectively tamping concrete components, it ensures a dense, uniform mix that significantly strengthens the final structure. It is an indispensable asset for critical construction projects, including bridges, tunnels, building foundations, and precast units.
Key Features
- Main Features
- Double oil-sealsAnti-reverse devicePushbutton modeAlloy steel 40Cr VibratorMN steel sheet flexible hoseCorrosion-resistant
Technical Specifications
Performance Data
| Parameter | CS35 | CS50 | CS70 |
|---|---|---|---|
| Vibration Freq (Hz) | 225 | 200 | 200 |
| Max Amplitude (mm) | 0.8 | 1.15 | 1.35 |
| Productivity (m³/h) | 7 | 13 | 23 |
| Poker Diameter (mm) | 36 | 51 | 68 |
| Flexible Shaft Dia (mm) | 10 | 13 | 13 |
Certifications
Quality Standards
CEISO 9001:2000ISO 9001:2008
