Multi-Material Wall Detector
This multi-material wall detector is designed for detecting studs, metal, and AC voltage behind walls. It features a clear LCD display and multiple scanning modes for different materials and depths.
Technical Specifications
Product Overview
Professional Multi-Material Wall Detector
This versatile multi-material wall detector is designed for accurate identification of studs, metal objects, and live AC voltage behind walls. Featuring an ergonomic design and an intuitive LCD display with backlight, it ensures reliable performance for construction, electrical, and home improvement projects. The device includes automatic calibration and power-off functions to maximize efficiency and battery life.
Technical Specifications
- Stud Detection Depth
- 19 mm
- Deep Wood Detection Depth
- 45 mm
- Metal Detection Depth
- 45 mm
- AC Voltage Detection Depth
- 50 mm
Electrical Characteristics
Operating Metrics
10 mA
Working Current
10 uA
Shutdown Current
- AC Voltage Range
- 90-250V, 50-60Hz
- Power Source
- 9V Battery
Features
- Key Features
- LCD DisplayBacklightAutomatic CalibrationAutomatic Power OffLow Battery Indicator
