Motorized Iris Lens for Surveillance
This high-precision lens is designed for surveillance and security applications. Its motorized iris allows automatic light control, ensuring optimal image quality in diverse lighting conditions.
Technical Specifications
Overview
High-Precision Motorized Iris Lens
The VPIRIS13 is a high-precision lens assembly engineered for demanding surveillance and security applications. Featuring a motorized iris for automatic light control, this component ensures optimal image quality across varying lighting conditions. The unit includes a compact motor, control circuitry on a PCB, and a flexible cable with a multi-pin connector for seamless integration into camera systems.
Electrical Specifications
- Iris Resistance
- 28.5 Ω
- IR Resistance
- 55 Ω
- IR Voltage
- 2.8 V
- Voltage Range
- 5V Max
Optical Specifications
- Max Effective Aperture
- 10.5 mm
- Glass Thickness
- 0.21
- Quantity of Glass
- 2
Mechanical & Connectivity
Wiring Configuration
| Pin | Wire Color | Function |
|---|---|---|
| 1 | Red | IR+ |
| 2 | Black | IR- |
| 3 | White | A- |
| 4 | Red | A+ |
| 5 | Black | B+ |
| 6 | Green | B- |
- Connector Type
- Molex 51021-0060
- Connector Pitch
- 1.25 mm
