Technical Specifications

Product Overview

Industrial Motor Protection

The J7K series thermal overload relay is engineered for reliable over-current protection in AC motor circuits. Designed for integration with CJX2 series contactors, this relay features advanced differential mechanisms and temperature compensation to ensure consistent performance. It adheres to international safety standards, making it an essential component for safeguarding industrial machinery.

Technical Specifications

Rated Voltage: 660 V
Rated Current: 38 A
Operating Frequency: 50Hz60Hz
Standard Compliance: IEC60947-4-1

Operational Features

Advanced Functionality

Differential mechanism for phase failure protection
Integrated temperature compensation
Test, Stop, and Reset functions
Plug-in compatibility with CJX2 series contactors

Control Contacts: 97NO95NC98NO96NC

Interested in Sourcing This Product?

Submit a request to connect with verified manufacturers who produce this product.

Motor Protection Thermal Overload Relay

This thermal overload relay is designed for motor protection in industrial applications. It features adjustable current settings and provides overload and phase failure protection, ensuring motor longevity and operational safety.

Request a Quote Download PDFPDF
