Modular Plastic Conveyor Belt with Nub Top
This modular plastic conveyor belt features a nub top surface for enhanced grip during conveyance. Constructed from food-grade plastic, it is easy to clean and sanitize for hygienic transport of meat and seafood products.
Technical Specifications
Overview
High-Performance Modular Conveyor Belt
This modular plastic conveyor belt features a specialized nub top surface designed to provide superior grip and product stability, making it ideal for the meat and seafood processing industries. Engineered for durability and hygiene, the belt is compatible with food-grade standards and offers easy maintenance through its modular design. With a high load capacity of up to 1.2 tons per square meter, it is built to withstand demanding industrial environments while facilitating efficient cleaning and sanitation processes.
Technical Specifications
Physical Dimensions
| Specification | Value |
|---|---|
| Pitch | 50.8 mm |
| Thickness | 19 mm |
| Minimum Width | 150.3 mm |
| Rod Diameter | 5.8 mm |
Operating Parameters
27 %
Open Area
1.2 tons/m²
Max Load Capacity
- Operating Temperature
- -40°C to 260°C
Design & Materials
Available Colors
WhiteBlueGrayNatureDark-brown
Key Features
- Nub Top Surface
- Flight Included
- Floating in water
- Food defrosting capable
- Maintenance-free
System Compatibility
- Sprockets: 6T, 8T, 10T, 12T (Standard and N-series)
- Bore Types: Square and Round
- Available Materials
- PPPOMPEPA
Compliance & Applications
Industry Applications
- Meat & Poultry Processing
- Seafood Processing
- Bakery & Snack Food
- Fruit & Vegetable Processing
- Automotive & Tire Manufacturing
- Packaging & Printing
- Postal & Logistics
- Certifications
- FDA ApprovedEU Approved
