Modular Plastic Conveyor Belt with Flush Grid
This modular plastic conveyor belt features a flush grid design for efficient drainage. It is constructed from durable, food-approved materials suitable for various applications.
Technical Specifications
Overview
High-Performance Flush Grid Conveyor Belt
This modular plastic conveyor belt is engineered for demanding industrial environments, particularly in the food and water processing sectors. Featuring a flush grid design, it offers superior drainage and airflow capabilities, which helps prevent product accumulation and maintains high hygiene standards. The modular construction ensures easy assembly, maintenance, and customization, significantly reducing downtime and operational costs compared to traditional belt systems.
Technical Specifications
- Pitch
- 25.4 mm
- Thickness
- 8.6 mm
- Minimum Width
- 84 mm
- Open Area
- 42 %
- Rod Diameter
- 4.5 mm
- Working Temperature
- -40°C to 260°C
- Available Materials
- PPPOMPEPA
- Available Colors
- WhiteBlueGrayNatureDark-brown
Configuration
Sprocket Dimensions
- 12T-2R
- 18T-2R
- 20T-2R
- Square bore & Round bore options
Belt Features
- Flight: No
- Side Guard: No
- Curve: No
Compliance & Performance
Certifications
FDAEU
Max Load Capacity
1.2 tons/sqm
Maximum Load
Applications
Industry Applications
| Sector | Applications |
|---|---|
| Food Industry | Meat, Poultry, Sea Food, Bakery, Snack Food, Fruit & Vegetables |
| Non-food Industry | Automotive, Packaging, Printing, Postal, Can/PET Manufacturing |
