LTE GPS Terminal for Vehicle Tracking
This LTE GPS terminal is designed for vehicle tracking and monitoring. It supports LTE/WCDMA/GSM cellular communication and features an internal 270mAh battery.
Technical Specifications
Product Overview
Professional Vehicle Tracking Terminal
The JM-VL02 is a high-performance LTE Cat M1 & NB2 fleet tracker engineered for reliable vehicle monitoring. Featuring a sensitive MTK GPS chipset and extensive interface support, it provides precise location data in diverse environments. With a wide operating voltage range and robust internal battery backup, this terminal is an ideal solution for comprehensive fleet management and security.
Performance Metrics
Key Performance Indicators
10 meters
Location Accuracy
1 sec
Hot Start TTFF
300 mAh
Battery Capacity
Connectivity
Maximum Data Transmission
| Network Type | DL Speed | UL Speed |
|---|---|---|
| LTE Cat M1 | 588kbps | 1.119Mbps |
| LTE Cat NB2 | 127kbps | 158.5kbps |
- LTE Bands Supported
- B1B2B3B4B5B8B12B13B20B66
Interfaces
Physical Interfaces
- Digital Input: ACC, IN1, SOS
- Digital Output: Relay, OUT
- 5V Controllable Output (500mA drive)
- UART (TTL)
- ADC (0-30V detection range)
- 1-wire Interface (Temperature sensor support)
Technical Specifications
Power Requirements
- Operating Voltage: 9V to 36V DC
- Standby Current: 5mA
- Battery: 3.7V Li-Polymer
Operating Environment
- Operating Temperature: -20°C to +70°C
- Dimensions: 105.5 x 57 x 21.8 mm
