Indoor AC Metal-Enclosed Switchgear
This metal-enclosed switchgear is designed for indoor AC power distribution in a three-phase 50Hz system. It provides control, protection, and monitoring of electrical circuits for efficient energy management.
Technical Specifications
Product Overview
High-Performance Power Distribution
This metal-clad removable indoor AC metal-enclosed switchgear is engineered for three-phase AC 50Hz power systems. It is designed to safely receive and distribute electric energy while providing essential circuit control, protection, and monitoring. The system is particularly suitable for high-current applications and can effectively serve as a high-voltage generator outlet.
Technical Standards
- Standards Compliance
- GB3906GB/T11022IEC298
Technical Specifications
System Parameters
50 Hz
Frequency
1 kV
Min Rated Voltage
52 kV
Max Rated Voltage
Key Features
- Metal-clad enclosure
- Removable circuit breaker design
- Suitable for high-current applications
- Three-phase AC compatibility
- Modular configuration
