Hydraulic Powder Briquetting Press
This hydraulic briquetting machine is designed for compacting various ore powders, metal powders, coal, coke, and other materials. It applies high pressure to create dense, uniform briquettes for easier handling and increased value.
Technical Specifications
Overview
High-Efficiency Briquetting Solution
This hydraulic briquetting press is engineered for the high-density compaction of various materials, including non-ferrous and ferrous metal mineral powders, coal, and coke. Featuring robust construction with wear-resistant rollers and computer-based PLC control, it ensures reliable, continuous operation in demanding industrial environments. The system is designed to increase the value of metallurgical waste and industrial by-products by converting them into uniform, easy-to-handle briquettes suitable for direct furnace use.
Key Features
Design Highlights
- Computer-based PLC control system
- 650mn hardness material rollers for wear resistance
- Mandatory squeeze rollers for high density and strength
- Optional crusher and conveyor integration
- Suitable Materials
- Ore PowderMetal PowderCoalCokeIndustrial Gasification WasteRefractory Materials
Technical Data
Model Specifications
| Model | Output (t/h) | Power (kw) | Weight (t) |
|---|---|---|---|
| 1000 | 15-20 | 45 | 13 |
| 850 | 10-15 | 37 | 7.5 |
| 750 | 8-13 | 30 | 5 |
| 650 | 9-14 | 22 | 4 |
| 500 | 6-9 | 15 | 3 |
| 430A | 5-7 | 11 | 2.4 |
| 360A | 3-6 | 7.5 | 2 |
| 290 | 1-3 | 5.5 | 0.7 |
