Gigabit Ethernet Fiber Media Converter
This Ethernet fiber media converter supports 10/100M and 10/100/1000M speeds with IEEE802.3ah OAM manageability. It allows real-time supervision and parameter setting of remote fiber media converters.
Technical Specifications
Overview
Gigabit Ethernet Fiber Media Converter
This manageable Ethernet fiber media converter supports 10/100/1000M speeds and features IEEE802.3ah OAM compliance for real-time monitoring of remote devices. Designed to enhance network maintenance and reduce operational expenditure, it provides comprehensive management capabilities including web-based configuration, SNMP monitoring, and VLAN support. It is an ideal solution for operators looking to improve service quality and network visibility.
Key Features
Network & Security
- Loop Detection
- Broadcast/Multicast/Unicast Storm Control
- 16 IEEE 802.1Q VLAN groups
- Q-in-Q VLAN
- 16 TCP/UDP Filter groups
- Management Features
- Web InterfaceSNMP v1/v2cRemote ManagementFirmware UpgradeEvent Traps
Technical Parameters
Ethernet Interface
| Parameter | Specification |
|---|---|
| Standards | IEEE802.3, 802.3u, 802.3z, 802.3ab, 802.3x |
| Data Rate | 10/100/1000 Mbps |
| Connector | RJ-45 |
| Transmission Distance | 100m (UTP CAT5/5E) |
Optical Port Specifications
- Connectors: ST, SC, FC, LC
- Multi-mode Wavelengths: 850nm, 1310nm
- Single-mode Wavelengths: 1310nm, 1550nm
- Dual Fiber Distance: Up to 100km
- Single Fiber Distance: Up to 80km
Power Requirements
5 W
Max Power Consumption
Environment & Dimensions
- Physical Dimensions
- 156mm (W) x 128mm (D) x 32mm (H)
- Operating Temperature
- 0°C to +50°C
- Storage Temperature
- -20°C to +70°C
