Gas Insulated Switchgear for High-Voltage Applications
This gas-insulated switchgear (GIS) is designed for high-voltage electrical applications. It features SF6 gas insulation within a compact, grounded metal enclosure, providing protection against environmental factors and reducing the risk of electrical faults.
Technical Specifications
Product Overview
ZF10-126G(L) Series Overview
The ZF10-126G(L) gas-insulated switchgear is designed for 126kV high-voltage power transmission and distribution systems. Featuring a compact, three-phase metal-enclosed design, it offers exceptional environmental protection and operational reliability. The system supports both traditional control interfaces and modern intelligent digital control technologies to suit varied substation requirements.
Technical Standards
- Certifications & Standards
- GB7674-2008IEC60517-1990
Operating Conditions
- Rated Voltage
- 126 kV
- Frequency
- 50 Hz
- Rated Altitude
- 1000 m
Environmental Ratings
Seismic Resistance
0.4 g
Horizontal Acceleration
0.2 g
Vertical Acceleration
Creepage Distance
| Pollution Class | Distance |
|---|---|
| Class III | 25 mm/kV |
| Class IV | 31 mm/kV |
- Ambient Temperature
- -35°C to +40°C
