Double Hole Copper Cable Lug
These copper compression lugs are designed for secure and reliable cable terminations, ideal for double-hole cable connections. They ensure optimal conductivity and mechanical strength.
Technical Specifications
Product Overview
High-Performance Copper Cable Lugs
These double-hole copper compression lugs are engineered for secure and reliable cable terminations in power distribution and electronic equipment. Manufactured from 99.99% pure T2 copper with a durable tin-plated surface, they ensure excellent conductivity and corrosion resistance. Designed to operate effectively in extreme temperatures ranging from -55°C to 150°C, these lugs meet rigorous international safety and quality standards.
Technical Specifications
Operating Temperature Range
-55 °C
Min Temperature
150 °C
Max Temperature
- Material
- 99.99% Pure Copper (T2)
- Surface Treatment
- Tin-plated
- Compatible Conductor Range
- 1.25 - 5.5 mm²
Certifications & Standards
Safety Certifications
CEUL
- Compliance Standards
- JISDINAWG
Dimensional Data
Standard Dimensions
| Item No | OD | ID | F | B | L | T |
|---|---|---|---|---|---|---|
| TPIN1.25 | 3.4 | 1.7 | 2 | 4.5 | 16.3 | 0.75 |
| TPIN2 | 4 | 2.3 | 2 | 4.8 | 17 | 0.75 |
| TPIN5.5 | 5.6 | 3.5 | 2.7 | 6.8 | 20.5 | 1 |
