Technical Specifications
Overview
Professional Concrete Floor Saw
This high-performance floor saw is engineered for durability and precision in both concrete and asphalt cutting applications. Featuring a reinforced steel box frame, the design effectively minimizes vibration to ensure straight, accurate cuts while extending the lifespan of both the saw and the blade. Equipped with a reliable air-cooled engine, this unit offers robust power, an integrated water cooling system for dust suppression, and user-friendly controls like an easy-crank depth adjustment for efficient operation on job sites.
Performance
Engine Power
9.8 kW
Power (kW)
13 HP
Power (HP)
Cutting Capabilities
| Metric | Value |
|---|---|
| Max Cutting Depth | 14 cm (5.5 in) |
| Blade Size Range | 30-40 cm (12-16 in) |
Design & Build
Key Construction Features
- Reinforced steel box frame for reduced vibration
- Japanese shaft bearings for extended service life
- Hinged, lift-up blade guard for easy maintenance
- Integrated water system for blade cooling
- Manual push driving mechanism
Physical Specifications
144 kg
Operating Weight
35 L
Water Tank Capacity
Operation
- Operational Controls
- Handle Rotation Depth AdjustmentManual Push DriveStandard Throttle ControlSaw Position Guide
