Air Rigging System for Material Handling
Air rigging systems use compressed air to lift and move heavy loads. The systems are used in manufacturing, warehousing, and other industrial settings.
Technical Specifications
Overview
Advanced Air-Film Material Handling
This air rigging system utilizes controlled air-leak technology to create a thin, frictionless film of air, enabling the effortless movement of heavy-duty loads. Designed for industrial environments, it allows operators to maneuver massive objects with minimal physical force while maintaining high safety standards. It serves as an ideal solution for applications where traditional lifting equipment is impractical, such as in cleanrooms or areas with restricted headroom.
Technical Principles
- Operating Principle
- Air-film flotation via controlled air leak
- Friction Level
- Extremely low friction
System Components
Included Components
- Air bearings
- Air hoses
- Control unit
System Layout
| Component | Function |
|---|---|
| Main Input | Power and air supply distribution |
| Air Skates | Individual load-bearing points |
Applications
- Ideal Use Cases
- ManufacturingWarehousingCleanroomsHeavy-duty load transportSensitive equipment handling
