Air Caster Rigging System for Heavy Load Movement
Air caster rigging systems utilize compressed air to lift and move heavy loads with minimal effort. These systems allow for precise and synchronized lifting and movement.
Technical Specifications
Overview
Precision Heavy Load Movement
The Air Caster Rigging System utilizes advanced pneumatic technology to create a thin film of air, enabling near-frictionless, omnidirectional movement of heavy loads. Designed for industrial environments, this system eliminates floor damage while providing precise control for positioning bulky items in tight spaces. It is an economical and safe solution for assembly, plant relocation, and equipment maintenance.
Performance
Load Capacity Range
1 ton
Minimum Capacity
50 ton+
Maximum Capacity
- Movement Capabilities
- OmnidirectionalLow FrictionLow ProfileSynchronized Lifting
Technical Specifications
System Components
- Air casters
- Control manifold/unit
- Pneumatic hoses
Surface Compatibility
ConcreteSteelEpoxy-coated floors
- Operating Requirements
- Utilizes existing shop compressed air
Applications
Common Use Cases
- Assembly to shipping transport
- Plant start-up and relocation
- Jacking and rotating assemblies
- Aligning machines over footings
- Rearranging production lines
- Repair of large items (heat exchangers, transformers)
