Achromatic Doublet Lens
This achromatic doublet lens maintains a consistent focal length, regardless of aperture. It delivers enhanced off-axis performance by minimizing chromatic aberration.
Technical Specifications
Overview
High-Precision Achromatic Doublet Lens
These achromatic doublet lenses are engineered to minimize chromatic aberration by bringing multiple wavelengths of light into a single focal point. Constructed with high-quality optical materials, they provide superior image resolution and clarity for demanding optical systems. Ideal for applications such as microscopy, laser beam manipulation, and advanced imaging, these lenses offer reliable performance across a broad spectrum.
Optical Specifications
Surface Quality
60-40 scratch-dig
- Design Wavelengths
- 480.0 nm546.1 nm643.8 nm
- Clear Aperture
- 80 %
- Surface Irregularity
- λ/4 per 25mm at 632.8nm
Mechanical Specifications
- Diameter Range
- 2.0mm - 90.0mm
- Diameter Tolerance
- +0.0, -0.10mm
- Centration
- 3 arc minutes
- Protective Bevel
- Yes
Manufacturing
Coating Options
- Single layer AR coating
- Broadband AR coating
