6x4 Heavy-Duty Dump Truck
This 6x4 heavy-duty dump truck is designed for transporting and unloading bulk materials. Its robust chassis and powerful engine ensure reliable performance in demanding environments.
Technical Specifications
Overview
Heavy-Duty 6x4 Dump Truck
This heavy-duty 6x4 dump truck is engineered for demanding construction and mining environments, offering a robust chassis and a high-capacity 16 cubic meter cargo bed. Equipped with a powerful 420hp engine and a reliable hydraulic lifting system, it ensures efficient material transport and unloading. The vehicle features a comfortable, ergonomic cabin design with advanced suspension and safety systems, providing operator comfort and stability across various terrains.
Performance & Engine
Engine Performance
420 hp
Horsepower
11.81 L
Displacement
1,930 N.m
Max Torque
Engine Specifications
- Four-stroke, water-cooled, in-line, direct-injection
- 1900 RPM rated speed
- Dry paper element air cleaner
- Euro II emission standard
Dimensions & Capacity
Vehicle Dimensions
| Dimension | Value (mm) |
|---|---|
| Overall Length | 8,480 |
| Overall Width | 2,495 |
| Overall Height | 3,360 |
| Wheelbase | 5,250 |
Weight Specifications
12,150 kg
Kerb Weight
25,000 kg
Gross Vehicle Weight
Cargo & Hydraulics
Dump Box Details
- Capacity: 16 cubic meters
- Internal Dimensions: 5800 x 2350 x 1200 mm
- Front lifting mechanism
- Bottom thickness: 6mm
- Side thickness: 4mm
Chassis & Drivetrain
Axle Capacities
7.5 T
Front Axle
16 T
Rear Axle
- Transmission
- Mechanical & manual with servo, synchronizer, and creep. 9 forward ratios and 1 reverse ratio.
Cabin & Comfort
- Cabin Features
- Flat RoofSingle BerthAir ConditioningMP3 PlayerHydraulically Damped SeatPower Windows
Safety & Electrical
Braking System
- Dual circuit compressed air brake
- Drum braking
- Spring energy parking brake
- Engine exhaust auxiliary brake
- ABS included
