4.5 Ton Lithium Battery Electric Cargo Truck
This 4.5-ton electric truck is equipped with a lithium battery for zero-emission operation. It offers a cost-effective and environmentally friendly solution for urban transportation.
Technical Specifications
Overview
High-Efficiency 4.5 Ton Electric Cargo Solution
The QX5040EV is a pure lithium battery electric truck designed for high-performance urban logistics with zero emissions and low noise operation. Engineered for the European and American markets, it offers a sustainable alternative to fuel vehicles with significantly lower operating costs—approximately 26% of traditional fuel expenses. This 4.5-ton truck features advanced energy recovery during braking and downhill driving to maximize efficiency and endurance.
- Key Features
- Pure ElectricZero EmissionLow NoiseGreen TechnologyRegenerative Braking
Performance Metrics
Performance Highlights
90 KM/H
Max Speed
300 KM
Max Endurance
26 %
Gradeability
- 0-50km/h Acceleration
- 10-15 Seconds
- Min. Turning Radius
- 7 m
Dimensions & Weight
Vehicle Dimensions
| Parameter | Value |
|---|---|
| Overall L×W×H | 5900×2050×2790 mm |
| Wheelbase | 3300 mm |
| Front/Rear Overhang | 1100 / 1650 mm |
| Ground Clearance | 200 mm |
Weight Specifications
| Type | Weight | Unit |
|---|---|---|
| Gross Weight | 4,495 | KG |
| Curb Weight (No Box) | 2,805 | KG |
Powertrain
Motor Specifications
- Type: Permanent Magnet Synchronous Motor
- Peak Power: 134kw (Rated: 75kw)
- Peak Torque: 720 N·m (Rated: 358 N·m)
- Max RPM: 4000 rpm
- Battery Type
- Ternary Lithium Battery
- Rated Battery Power
- 72.1 KWh
Chassis & Safety
Axle Loading Capacity
- Front Axle: 1800 KG
- Rear Axle: 3500 KG
- Rear Axle Ratio: 6.167
Tyre Specification
6.50R16LT 12PR
- Braking System
- Integral hydraulic four-channel ABS (Front Disc / Rear Drum)
Supply & Logistics
Available Shipping Formats
- CBU (Completely Built Up): Bare/Naked via RO-RO
- SKD (Semi Knocked Down): Specialized export frames/brackets
- CKD (Completely Knocked Down): Anti-corrosion iron frame packing
- OEM/Customized packing available
- Primary Export Ports
- WuhanShanghai
