24V DC Linear Actuator for Industrial Automation
This 24V DC linear actuator is designed for industrial applications requiring precise and controlled linear motion. It is suitable for automation and mechanical systems, offering reliable performance in demanding environments.
Technical Specifications
Overview
High-Performance Industrial Linear Actuator
This robust linear actuator is engineered for demanding industrial automation tasks, providing precise and reliable linear motion. Designed with a durable stainless steel construction and an IP65 protective rating, it excels in environments ranging from medical equipment to heavy industrial machinery. With versatile power options and adjustable stroke lengths, it offers a flexible solution for automated positioning and force exertion.
Technical Specifications
Protection Class
IP65
- Input Voltage
- 12V / 24V / 36V / 48V DC
- Max Push Force
- 7000 N
- Speed
- 5~40 mm/s
- Stroke Length
- 100-600 mm (Optional)
- Duty Cycle
- 25 %
- Operating Temperature
- -26 to 65°C
Construction & Design
- Housing Material
- Stainless Steel
- Cover Color
- Black
- Min Installation Size
- S+280mm (Adjustable)
Compliance & Quality
- Certifications
- CEEMCLVDISO9001:2008
- Expected Lifespan
- >10,000 cycles
Applications
Primary Applications
- Medical care beds
- Operating tables
- Traction beds
- Massage chairs
- Dental chairs
- Furniture and sofas
- Industrial electric equipment
