1x2 Optical Fiber Switch
This 1x2 optical switch features low insertion loss and high switching speed. It is designed for optical fiber communication networks and measurement instruments, with ports that selectively transmit, redirect, or block optical power.
Technical Specifications
Overview
High-Performance 1x2 Optical Switch
The 1x2 optical fiber switch is engineered for demanding optical fiber communication networks and precision measurement instruments. It features a compact design that delivers low insertion loss, high switching speed, and low driving power requirements. Designed for reliability, this switch provides essential signal routing capabilities and robust performance in critical transmission lines.
Key Features
Key Features
- High Extinction Ratio
- Low Insertion Loss
- High Channel Isolation
- Highly Stable and Reliable
- Epoxy-Free Optical Path
Performance Metrics
- Operating Wavelengths
- 850 nm1310 nm1490 nm1550 nm1625 nm
- Insertion Loss
- 0.6 dB
Applications
Typical Applications
Optical Signal RoutingNetwork Test SystemsInstrumentation
