1800W Class AB Full Frequency Car Amplifier
This Class AB car amplifier delivers 1800W for full-frequency channel applications. It is designed to provide clean and powerful amplification, enhancing the sound quality and volume of car audio setups.
Technical Specifications
Overview
High-Performance Class AB Car Power Amplifier
The CD-600.1-D is a robust 1800W Class AB full-frequency car amplifier engineered for professional audio performance. It offers versatile power delivery across various impedances and features comprehensive frequency controls to optimize sound quality for any vehicle setup. With built-in protection circuits and a durable heat sink design, it ensures reliable operation and clean, powerful amplification for demanding car audio enthusiasts.
Power Performance
RMS Power Output
200 W
RMS Power @ 4 Ohms
350 W
RMS Power @ 2 Ohms
600 W
RMS Power @ 1 Ohm
Audio Specifications
- Frequency Response
- 10Hz - 47kHz
- Signal-to-Noise Ratio
- >92dB
- THD + Noise
- <0.01%
- Variable Input Level
- 0.2V - 6V
Frequency Control
High Pass Frequency Range
- 20Hz - 120Hz
- 120Hz - 700Hz
- 700Hz - 4.1kHz
Low Pass Frequency Range
- 50Hz - 215Hz
- 215Hz - 925Hz
- 925Hz - 4kHz
- Bass Boost Function
- 0dB - 12dB
Physical Characteristics
- Dimensions
- 402 x 225 x 60 mm
- Unit Weight
- 4.3 kg
Protection & Safety
- Integrated Protection
- Over-voltageOver-currentThermal OverloadStatus Indicator LEDs
Connectivity
Connection Terminals
- Electrical Output Terminals
- Horn Input Terminals
- 12V Battery Input
- Audio Signal Input/Output (RCA)
