Technical Specifications
Overview
High-Capacity Water Distribution Solution
This 17000L water distribution truck is engineered for heavy-duty performance in road maintenance, construction site dust suppression, and large-scale irrigation. Built on an 8x4 drive chassis, it combines a massive tank capacity with a robust 380hp engine to ensure reliable operation across demanding terrains. The vehicle is fully equipped with advanced sprinkler systems, including front and rear sprayers and a water cannon, making it a versatile asset for professional water management.
Vehicle Dimensions & Weight
- Chassis Dimensions (LxWxH)
- 10300×2540×3300mm
- Curb Weight
- 13000 kg
- Gross Vehicle Weight (GVW)
- 31000 kg
Engine & Performance
Engine Performance
380 ps
Horsepower
9,839 ml
Displacement
6 In-line
Cylinders
- Transmission
- 8 Speed Manual (8 Forward, 2 Reverse)
Chassis & Drivetrain
- Drive Type
- 8x4
- Wheelbase
- 1850+3280+1370mm
- Tire Configuration
- 13 (including spare), 12R22.5 16PR
Tanker Specifications
- Tank Capacity
- 17000 L
- Tank Material
- Carbon Steel
- Tank Thickness
- 5mm (6mm seal head)
Equipment & Features
Sprinkler System Equipment
- Front dash spray
- Rear & side sprinkler
- Water cannon
- Gravity valve
- Fire interface
- Working platform
- Standard Features
- Power SteeringAir ConditioningTubeless TiresABSMaintenance-Free BatteryCentral LockPower WindowsDriving Data Recorder
