16mm Benchtop Drill Press
This bench drill press is designed for precision drilling tasks with a 16mm capacity. It features adjustable spindle speeds and a sturdy construction for reliable performance.
Technical Specifications
Overview
Professional 16mm Benchtop Drill Press
The ZX-16J is a high-performance benchtop drill press engineered for precision and durability in professional workshop environments. Featuring a 370W motor and a versatile 12-speed configuration, this machine provides optimal drilling control for a wide range of materials. Its robust construction and adjustable work surface make it an essential tool for demanding drilling applications requiring consistent accuracy.
Performance
Motor Power
370 W
Motor Power
- Max Borehole Diameter
- 16 mm
- Spindle Speed Range
- 250-3200 RPM
- Speed Settings
- 12
Technical Dimensions
- Spindle Stroke
- 85 mm
- Spindle Center to Column Surface
- 182 mm
- Table Itinerary
- 365 mm
- Column Diameter
- 72 mm
- Desk Size
- 310 mm
Specifications
Weight Specs
| Metric | Value |
|---|---|
| Net Weight | 65 kg |
| Gross Weight | 69 kg |
- Spindle Taper
- MT2
Logistics
- Packing Dimensions
- 785 x 460 x 280 mm
- Total Height
- 992 mm
