Benchtop Drill Press for Metalworking
This drill press is designed for creating accurate and repeatable holes in various materials. It features an adjustable worktable for precise workpiece positioning and a depth stop for consistent drilling depths.
Technical Specifications
Overview
Professional Benchtop Drill Press
This Benchtop Drill Press is engineered for precision drilling in metalworking and various other materials, featuring a robust cast aluminum table and a sturdy 70mm column for maximum stability. With a 5-speed range from 600 to 2600 RPM and a powerful motor, it provides the versatility needed for accurate, repeatable holes in professional and DIY environments. Safety is prioritized with an integrated chuck guard and emergency stop functionality, ensuring a reliable performance for every project.
Performance Metrics
Key Performance Indicators
630 W
Max Power (S2 15min)
16 mm
Chuck Capacity
50 mm
Spindle Travel
290 mm
Swing
Technical Specifications
- Voltage
- 230 V / 50 Hz
- Motor Speed
- 1450 /min
- Speed Range
- 5 speeds (600 - 2600 RPM)
- Spindle Taper
- B16
Worktable & Base
Table Material
Cast Aluminum
- Table Size
- 211 x 211 mm
- Table Tilt Range
- -45° to +45°
- Base Dimensions
- 440 x 300 mm
Physical Dimensions
- Column Diameter
- 70 mm
- Total Machine Height
- 1440 mm
Features
- Safety & Control
- Chuck GuardEmergency StopDepth StopVariable Speed Control
