16-Slot Managed Media Converter Chassis
The managed chassis media converter supports remote network management via SNMP, web-based, and console methods. It supports media converter series, creating a centrally located SNMP managed chassis solution.
Technical Specifications
Overview
High-Density Managed Chassis
This 16-slot managed media converter chassis provides a centralized, rack-mountable solution for network media conversion. It supports comprehensive management via SNMP, Web-based interfaces, and console access, ensuring robust control over your network infrastructure. Designed for reliability, the system features hot-swappable modules and redundant power supply configurations, making it an ideal choice for enterprise-grade data centers and telecommunication networks.
Technical Specifications
Power Options
Single Power SupplyDual Power SupplyRedundant ModeAC/DC Support
- Total Slots
- 17 slots
- Form Factor
- 2U Rack Mount
- AC Input Voltage
- 85-265V
- DC Input Voltage
- -36 to -72V
- Max Power Consumption
- 95 W
- Dimensions
- 430mm (D) x 368mm (W) x 112mm (H)
Environmental
- Operating Temperature
- -10 to 55°C
- Operating Humidity
- 5% to 90%
Management Features
Management Interfaces
- SNMP Management
- Web-based Management
- Console Port (Local)
- Telnet
- Maintenance
- Hot SwappableOnline Software UpgradeTFTP SupportRemote Management
