Technical Specifications
Product Overview
Continuous Slot Wedge Wire Technology
These wedge wire screen tubes are engineered with a precision-welded v-shaped wire wrapped around longitudinal support rods, creating a continuous slot opening. This robust design facilitates high-capacity fluid flow while effectively managing sand and gravel exclusion. Ideal for demanding filtration applications, these screens offer exceptional durability, anti-clogging performance, and customizable configurations.
Technical Specifications
Open Area
60 %
Maximum Open Area
- Slot Size
- 0.1mm - 5mm
- Unit Length
- 6 meters
- Diameter Range
- 25mm - 1500mm
Materials and Standards
Standards Compliance
- DIN
- GB
- ISO
- JIS
- Material Options
- Stainless Steel 304Stainless Steel 316LLow Carbon SteelGalvanized SteelDuplex Stainless SteelPVC Painted
Connection and Configuration
End Connections
Plain Beveled EndsThreaded CouplingFlangeWelding Ring
