Technical Specifications
Product Overview
High-Efficiency Wire Wrap Screens
These professional-grade wire wrap screens are engineered for superior sand control and high-volume water intake. Featuring a non-clogging V-shaped slot design, these screens ensure maximum open area and consistent flow rates across diverse environmental and geothermal drilling applications. Constructed from durable, high-quality materials, they offer robust reliability for demanding water and gas utility projects.
Technical Specifications
Size Range
2 inch
Min Diameter
45 inch
Max Diameter
6 meters
Max Length
Slot Size Details
- 0.10 mm
- 0.15 mm
- 0.20 mm
- 0.25 mm
- 0.30 mm
- Up to 3.00 mm
- Construction Materials
- Low carbon galvanized steelPlastic sprayed steelStainless Steel 304Stainless Steel 316
- Efficiency
- 60 % Open Area
Design and Application
End Connections
Plain beveled endsThreaded
Suitable Applications
- Water well drilling
- Geotechnical drilling
- Environmental drilling
- Mineral exploration
- Geothermal drilling
- Construction drilling
- Water/Gas utility leak detection
