Vehicle DC Motor
This DC motor is designed for vehicle applications. It features a robust design and an integrated electrical connector.
Technical Specifications
Product Overview
VDR38 Series Vehicle DC Motor
The VDR38 is a robust 12V DC motor specifically engineered for demanding automotive environments. Featuring a compact cylindrical design, it integrates seamlessly into vehicle systems via a multi-pin connector. It offers reliable performance with stable speed control and a power output suitable for various vehicle-based applications.
Performance Metrics
Core Operational Metrics
3,050 RPM
No-Load Speed
2,400 RPM
Load Speed
66 W
Power Output
0.35 N·m
Stalling Torque
- Rated Voltage
- 12 V
Electrical Specifications
Electrical Limits
| Parameter | Value |
|---|---|
| No-Load Current | 1A max |
| Load Current | 5.5A max |
| Stalling Current | 16A max |
| Internal Components | Varistor, PTC |
Technical Features
Design Characteristics
- Cylindrical metal housing
- Black plastic end cap
- Integrated multi-pin electrical connector
- Compact form factor for flexible mounting
- Rotation
- CWCCW
