Vacuum Cleaner Motor 600-800W
This vacuum cleaner motor provides high efficiency. It operates within a power range of 600-800W.
Technical Specifications
Product Overview
High-Performance Vacuum Cleaner Motor
The HWX-CG16(D) is a professional-grade vacuum cleaner motor engineered for high suction efficiency and reliability. Designed to support diverse power requirements ranging from 600W to 1200W, it ensures consistent operation across different vacuum models. With integrated cooling and robust internal components, this motor provides a balanced solution for both replacement parts and new product development.
Performance Metrics
Performance Metrics
38 %
Max Suction Efficiency
96 dB
Noise Level
115 K
Temperature Rise
Technical Ratings
| Input Power (W) | Vacuum (Kpa) | Airflow (m³/min) |
|---|---|---|
| 600 | 17 | 2.4 |
| 800 | 19 | 2.5 |
| 1,000 | 21 | 2.6 |
| 1,200 | 24 | 2.8 |
Electrical Specifications
Electrical Characteristics
- Model: HWX-CG16(D)
- Voltage: 100-240V
- Frequency: 50/60 Hz
- Spark Grade: <2
