Technical Specifications
Product Overview
High-Performance Type B RCCB
This Type B Residual Current Circuit Breaker provides comprehensive protection against earth faults and leakage currents, including a vital isolation function. Designed with high short-circuit withstand capacity and fire-resistant plastic components, it ensures reliable safety in demanding residential and industrial environments. The device features an automatic disconnect mechanism that triggers when leakage exceeds rated sensitivity, alongside a clear contact position display for operational monitoring.
Key Metrics
Featured Specifications
6 kA
Breaking Capacity
0.1 s
Action Time
400 V
Max Voltage
Technical Parameters
Rated Current (In)
- 25A
- 32A
- 40A
- 63A
- 80A
- 100A
Rated Voltage (Un)
| Configuration | Voltage | Frequency |
|---|---|---|
| 2P | 230V | 50/60Hz |
| 4P | 400V | 50/60Hz |
- Model Series
- VT7R / EBS9RN-100
- Standard
- IEC61008
- Poles
- 2P4P
Protection Characteristics
Residual Current Type
Type B
Rated Residual Operating Current (IΔn)
- 30
- 100
- 300
- Rated Residual Non-operating Current
- 0.5 IΔn - IΔn
Installation & Build
- Busbar Connection
- TerminalPin TypeU Type
- Housing Material
- Fire resistant plastic, impact resistant
Certifications
International Approvals
CETUVKEMACBSEMKORoHSCCC
