Trapezium Grinding Mill for Mineral Processing
The Trapezium Grinding Mill is an advanced solution for material processing in mining and industrial applications. Its trapezium-shaped grinding assembly enhances efficiency and reduces energy consumption.
Technical Specifications
Product Overview
High-Efficiency Grinding Technology
This European-style grinding mill is engineered for precision powder processing, leveraging advanced technology to meet rigorous industrial standards. Designed for versatility, it effectively handles a wide range of minerals including limestone, calcite, and gypsum, delivering consistent output fineness. The system features an optimized, compact design that maximizes production efficiency while minimizing floor space requirements.
Performance Metrics
Capacity
3 TPH
Minimum Capacity
50 TPH
Maximum Capacity
- Input Material Size
- 50 mm
- Output Fineness
- 200-33μm (80-425Mesh)
Technical Specifications
Key Design Features
- Split-type cambered shovel blade for increased working area
- Bevel gear transmission system
- Cambered air duct for low resistance
- Compact structure for reduced footprint
- Wear-Resistant Components
- Specialized alloy grinding rollers and rings with 1.7-2.5x longer service life than high manganese steel
Applications
- Suitable Materials
- LimestoneCalciteDolomitePetroleum coalGypsumBariteMarbleTalcCoal powder
