Technical Specifications
Product Overview
High-Performance Geothermal Submersible Pumps
The QJR Series is a comprehensive line of submersible borehole pumps engineered for high-temperature geothermal applications. With over 800 size configurations, these units are designed to handle demanding industrial, agricultural, and commercial water supply tasks. They combine advanced corrosion-resistant materials with high-efficiency hydraulics to ensure long service life and reliable operation in deep-well environments.
Performance Metrics
Operating Range
600 m3/h
Maximum Flow Rate
600 m
Maximum Head
250 KW
Max Power
Technical Specifications
Operating Conditions
- Max ambient temperature: 100°C
- Max immerging depth: 70m
- Rotation speed: 3000 r/min
- Well Compatibility
- 150mm to 400mm (5.9 to 15.7 inches)
- Supported Voltages
- 220V380V400V415V
Construction & Materials
Pump Materials
Cast IronStainless Steel
Applications
Typical Applications
- Medical treatment water supply
- Bathing and geothermal spas
- Aquaculture systems
- Industrial water processing
- Agricultural irrigation
