Rubber Block Cutter
This rotating-disc machine cuts natural, compound, reclaimed, and synthetic rubber. It processes rubber blocks into slices, granules, and bars, and can also cut other materials.
Technical Specifications
Overview
Professional Rubber Block Cutting Solution
This high-performance rotating-disc cutting machine is engineered for the efficient processing of natural, compound, reclaimed, and synthetic rubber blocks. Designed for industrial-grade reliability, it enables precise cutting into smaller blocks, slices, granules, or bars. The system features a hydraulic worktable and self-lubricating components to minimize friction, enhance operational longevity, and reduce manual labor requirements.
Technical Specifications
Machine Specifications
| Specification | WQJ-1000 | WQJ-1300 |
|---|---|---|
| Blade Diameter | 1000mm | 1300mm |
| Rotational Speed | 50 r/min | 50 r/min |
| Power Rating | 4+2.2 kW | 4+2.2 kW |
| Working Pressure | 5 Mpa | 5 Mpa |
| Production Capacity | 2 t/h | 3 t/h |
Key Features
Cutting Output Formats
- Smaller Blocks
- Slices
- Granules
- Bars
- Compatible Materials
- Natural RubberCompound RubberReclaimed RubberSynthetic Rubber
Operational Details
Performance Metrics
Operational Maintenance
The machine is delivered as a complete unit, requiring simple ground fixation according to the user manual before connecting to power. It utilizes a hydraulic system where hydraulic oil acts as the working medium, with self-lubricating moving parts to ensure reduced friction and an extended service life.
