Rod Mill Grinder
The rod mill grinder utilizes steel rods to crush and grind materials into fine powders. It is suitable for industries with high requirements on the uniformity of finished materials.
Technical Specifications
Product Overview
Industrial Grinding Efficiency
This industrial rod mill is designed for high-precision material reduction using steel rod grinding media. By facilitating line contact between media and ore, it achieves superior particle size uniformity and minimized over-crushing compared to ball mills. It is a robust solution engineered for sectors requiring strict finished material uniformity, including metallurgy, chemical engineering, and mineral processing.
Performance Specifications
Key Operating Metrics
50 mm
Max Feed Size
180 t/h
Max Capacity
Application Areas
- Industries Served
- MetallurgyMiningChemical EngineeringCoalRefractory ProductionCeramic Production
Technical Data
Model Performance Table
| Model | Capacity (t/h) | Power (kW) | Weight (kg) |
|---|---|---|---|
| MBS0918 | 0.62-3.2 | 18.5 | 5,500 |
| MBS0924 | 0.81-4.3 | 22 | 6,100 |
| MBS1224 | 1.1-4.9 | 30 | 12,000 |
| MBS1530 | 2.4-7.5 | 75 | 16,800 |
| MBS1830 | 4.8-11.6 | 130 | 29,000 |
| MBS2130 | 14-35 | 155 | 34,800 |
| MBS2136 | 19-43 | 180 | 37,000 |
