Technical Specifications
Overview
RG11 Coaxial Cable Overview
This RG11 coaxial cable is engineered for high-performance signal transmission in demanding environments, including cable television, satellite, and broadband infrastructure. Designed with a robust 1.63mm conductor and foam polyethylene insulation, it provides superior signal integrity and minimal attenuation over long distances. The multi-layer shielding construction ensures excellent interference protection, while the durable outer jacket offers reliable resistance to abrasion and environmental stressors.
Electrical and Physical Specs
- Inner Conductor
- 1.63mm Copper/CCS
- Dielectric
- 7.2mm PE-foam
- Outer Diameter
- 10 mm
Shielding Configuration
Braiding Specifications
| Parameter | Available Options |
|---|---|
| Braiding Diameter | 0.12mm, 0.15mm, 0.16mm |
| Wire Count | 72, 96, 120 and up |
| Shielding Coverage | 60%, 80%, 90% and up |
- Foil Layers
- AL+PolAL+Pol+ALBonded AL+Pol
- Braiding Material
- CopperAL-MgTinned Copper
